Symex HOT-ROD Torch
| HOT-ROD Torch | |||
|---|---|---|---|
| REF.# | DESCRIPTION | PART# | |
| 1 | Torch Collet Nut. | 10104 | |
| 2 | 1/4" Collet | 10102 | |
| 3 | 3/8" Collet | 10103 | |
| 4 | Rubber Collet Washer | 10105 | |
| 5 | Flash Arrestor Screen | 73010 | |
| 6 | Collet Barrel | 73005 | |
| 7 | Molded Shield Grommet | 73003 | |
| 8 | Steel Shield | 73001 | |
| 9 | Shield Screw | 73190 | |
| 10 | R. Plastic Housing | 73006 | |
| 11 | L. Plastic Housing | 73007 | |
| 12 | Brass Stud | 73008 | |
| 13 | Brass Nut | 73009 | |
| 14 | Male Oxygen Inlet | 73002 | |
| HOT-ROD Torch Cable & Hose Kit | |||
|---|---|---|---|
| REF.# | DESCRIPTION | PART# | |
| 1 | Torch, 10' Cable & Hose Kit | 70034 | |
| Kit includes the following: | 20760 | ||
| 2 | T68 Lug | 73182 | |
| 3 | #4 Welding Cable | 73183 | |
| 4 | Copper Striker Plate | 73184 | |
| 5 | 100 Amp Clip | 73185 | |
| 6 | Green Oxygen Hose, 1/4" | 73186 | |
